Non Contact Ultrasonic Level Sensor

NRG GLOBAL MAKE microprocessor based Ultrasonic level transmitter. It has Multifunction Instruments

It is capable of monitoring Virtually Any Short Or Medium Range of Non-Contact

Ultrasonic Level Measurements of Liquids, Solids Or Slurries. In this Instrument User

can take measurements of Roller Lift of mills, water level and select the range in the

range parameter and set Reverse action in Action parameter. It has One Analog Output

4-20mA and two digital control output (we can also define these two digital control

output as relay1and 2).

NOTE – To measure the level t of the tank ,the sensor has to be placed 22cm above the

level as it is defined as the dead zone of the sensor .

SPESCIFICATION

Measuring Range : 0-15 Meters

Main (auxiliary supply) : 24V DC

O/P (Analog) : 4-20mA

Digital (RL1&2) : +24v common

Display LCD : 16 x2

Display value : In CM And MM(Millimeter)

Revers Action : User can be take 4-20mA in revers action

ACTION PARAMETER - if we mention the value of action parameter as 1 then it will work in reverse order and if value is mentioned as 0 it will work in forward order. RANGE PARAMETER – in range parameter we have to define that value which gives the output of 420mA.

WORKING OF TRANSMITTER- (REVERSE ACTION ) if we mention the value of action parameter as 1 , suppose the object is placed 1 m (value of range parameter ) from the transmitter then this value will be considered zero and

as the object will move closer to it ,it will begin to sense the distance and will give the output as soon as when the object will be at 22cm it will display maximum range i.e 420 mA.
