Inclined Tube Manometer

Phone Number

08048032280

Please keep 0 before dialling the number.

Email Address salesnrgglobal@gmail.com

Mon-Thu: 10 AM - 2 PM • Fri: 3 PM - 7AM

Other Website Visit our other website

Address 986/20/1, Diamond Park Gate No. 2, G.I.D.C Industrial Estate, GIDC, Makarpura, Vadodara-390010, Gujarat, India

Vadodara, India, 390010

Description

Inclined Manometer Defination : Inclined Manometer : Range from 0 - 10 MM WC To 0 - 100 MM WC The is ainclined tube manometer scientific device, used to measure a very low pressure of liquid & gases. It is more suitable for measuring, very low pressure measurements or where greater accuracy is required. This inclined Tube is made by Acrylic or Plastic body.Manometer Working Principle : For measuring the pressure, one tube of the Inclined Tube Manometer forms into a reservoir & the other tube of the manometer is inclined, as per its required angle. After giving the pressure on its reservoir, which are filled with the suitable liquid, shows the changes, in the heights of the other tube or angle, of the Inclined Tube Manometer. Measuring Accuracy : The accuracy of measuring the pressure in the Inclined Tube Manometer, is easier for the Reader or end user , as he only judging or measuring, the pressure gives on its reservoir area, filled with the suitable liquid, of the Inclined Tube Manometer, which cause the liquid or Water or Mercury , to reach its require height in its single or angle tube area , of the Inclined Tube Manometer. Features : Clear, 25 mm drilled and Reamed Unbreakable acrylic block. Precision machined reservoirs and indicating column insure high accuracy. Zeroing is easy, using the sliding milky white scale, inbuilt preset spirit level for accurate mounting.
