Hcl Level

NRG GLOBAL MAKE Float & Board type level gauge is a weighing liquid level measuring system applicable for non-pressurized storage tanks/vessels. It is basically a balanced counterweight system with an arrow shaped pointer which smoothen the indication process. It is suitable for most liquid application media whose specific gravity is ≥ 0.8. Additionally, it effectively works in the phenomena of turbulence by ensuring stability using guided rope assembly with an anchor.

Installation available for Ground Level Tank, Overhead Level Tank and Underground Level Tank.

Wide Range Tank Height: Guided (up to 20m), Non-Guided (up to 8m)

Float Ø 280mm × 80mm (SS 316 with Tested Pressure 2kg/cm²)

Specific Gravity ≥ 0.8

Application Temperature Range : Up to 100° C

Adjustable Horizontal Pipe (500 to 1000 mm)

Wetted Parts : SS 316

Weatherproof Scale Board (SS 304 & Pure Polyester Powder Coated Aluminum)

Process Connection: Flanges

Radium Visibility from longer Distance

Additional Information:

Production Capacity: 100

Delivery Time: EX STOCK

Packaging Details: EXPORT WORTHY PACKING
